Light Weight Hand Push Up Antenna Mast Antenna Pole 9m 30ft
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | Aluminum | Sections | 6 |
---|---|---|---|
Max Load | 5kg | Extend Height | 9m |
Retracted | 1.7m | Accessories | Guyed Wires |
Tripod | Optional | ||
High Light | aluminum push up mast,Antenna Pole 9m 30ft,master push up |
model numner | HP series | |
---|---|---|
type | antenna pole | |
place of orginal | Jiangsu China | |
Full height | 3m--18m | |
Closed height | 1.2m --2.5m | |
max payload | 10kg | |
No.of sections | 3--10 | |
foot print | 80mm | |
material | aluminum | |
color | nature aluminum | |
optional color | available | |
top connection | M8 screw |
light weight hand push up antenna mast antenna pole 9m aluminum mast 30ft
Our Aluminum Telescoping Masts are convenient for many tasks. Made of a strong yet lightweight weather-resistant alloy, these metric-sized masts are primarily intended for temporary and portable use. The versatile masts have a range of uses, including vertical antenna construction, installation of weather stations, and mounting of a security camera. They're made of slotted aluminum tubing that can be extended to the desired length. Mast models are available with extended lengths of 3 to 18 meters. Each section can be locked solidly in place with the tips. Load capacity of the masts is determined by the clamping length and height; depending on the diameter, weights up to 5kg or more are possible. The maximum extension length of each section is limited by a slot and a spring pin above the bottom of the tube. The sizes of the telescoping aluminum tubing are in 5mm (0.197 in.) increments, with a nominal wall thickness of 2mm (0.079 in.).
model | HW06 | HW09 | HW12 | HW15 | HW18 |
EXTEND HEIGHT | 6M | 9M | M12M | M15M | M18M |
RETRACTED | 1.5M | 1.8M | 2M | 2.2M | M2.5M |
MAX LOAD | 5KG | 5KG | 5KG | 5KG | 5KG |
SECTIONS | 4 | 6 | 7 | 8 | 9 |
TOP SECTIONS | 35mm | 35mm | 35mm | 35mm | 35mm |
