3m hand winch up Mast light weight telescopic pole portable telescoping lighting mast 10ft
| Place of Origin | Jiangsu |
|---|---|
| Brand Name | QJ |
| Model Number | HW09 |
| Minimum Order Quantity | 1 set |
| Price | 600USD |
| Packaging Details | wood box |
| Delivery Time | 10days |
| Payment Terms | L/C, D/A, D/P, T/T |
| Supply Ability | 300 set per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Aluminum Or Steel | Erect Type | Hand Crank |
|---|---|---|---|
| Crank Capacity | 800lb | Extend Height | 9m |
| Transport Length | 1.8m | Sections | 5 |
| Max Load | 15kg | Accessories | Guyed Wires |
| Optional Parts | Tripod, Wheels |
You can tick the products you need and communicate with us in the message board.
| model numner | HW06 | |
|---|---|---|
| type | antenna mast | |
| place of orginal | Jiangsu China | |
| Full height | 6 | |
| Closed height | 7 | |
| max payload | 15kg | |
| No.of sections | 4 | |
| section diamter | 40/50/60/80 | |
| material | aluminum alloy | |
| color | nature color of aluminum alloy | |
| optional color | available | |
| top connection | M8/M10 screw | |
| accessories | guyed wires pack | |
| tripod | optional |
Product Description
15m hand winch up light weight telescopic pole portable telescoping pole lighting mast 50ft
A lightweight portable telescopic mast system available in a range of heights and headloads from 3 metres to 15metres, available in a variety of mountings, field mounted,
Our sturdy aluminum telescopic masts are perfect tools for elevated photography, survey stations, antenna deployment, sports filming, internet, ideal for either quick or permanent deployments. Available in extensions from 18ft to 60ft but still very portable. The widest base area from similar masts out there, offering the ultimate in stability and safety.
| model | HW06 | HW09 | HW12 | HW15 | HW18 |
| extend height | 6m | 9m | 12m | 15m | 18m |
| retracted | 1.7m | 1.8m | 2m | 2.2m | 2.5m |
| max load | 20kg | 15kg | 15kg | 10kg | 10kg |
| no. of sections | 4 | 5 | 6 | 7 | 8 |
| winch | 600lb | 800lb | 1200lb | 1500lb | 1500lb |
